    250KW 600Pcs/Min Elastic Band Waist Diaper Production Line

    Ask Lasest Price
    Brand Name : HAINA
    Model Number : HNJX-UNK600
    Certification : CE
    Price : Negotiable
    Payment Terms : T/T
    Supply Ability : 72 SETS / YEAR
    Delivery Time : 150 Days
    • Product Details
    • Company Profile

    250KW 600Pcs/Min Elastic Band Waist Diaper Production Line

    Full Automatic Elastic Band Waist I Shape Baby Diaper Machinery With Mitsubishi System


    MachineFull Servo High Speed 700 pcs/min Baby Diaper Machinery I Shape
    ModelHNJX-UNK600
    ProductsBaby Diaper
    Products StructureUpper & Lower tissue paper, Cotton core ( mix with SAP), ADL, PE film, frontal tape, topsheet hydrophilic nonwoven, leg cuff hydrophobic nonwoven, S cut side tape, waistband online.
    Product SizeNB, S, M, L, XL, XXL
    Glue MachineNordson / Chinese Brands Optional
    Design speed600 pcs/min
    Production speed500 pcs / min
    Defective rate≤3%
    Efficiency≥85%
    Power Supply3 Phase 380VAC, 50HZ (base on customer local power)
    Total Weight100 T customized
    Power~300KW
    Required Air Compressor2m³/min, 0.6-0.8Mpa
    DimensionL~42m,W~8.0,H~4m
    Machine directionFrom right to left or left to right (According to the customer requirements)
    ColorCustomized

    Elastic Waist Baby Diaper Schematic View



    Main Part Suppliers:


    NAME BRANDBRAND(Can be Customized)

    Servo motors & drivers,

    Unwinding Inverters

    Interface, control system

    MITSUBISHI / SIEMENS, Customized
    MotorsTeco motor, Taiwan
    Web guidersBST / FIFE
    Photo sensorSICK, Germany
    Temp. unitOMRON, Japan
    Lower electric partSchneider, France
    Solid relayOMRON, Japan
    Pneumatic parts(cylinders, values, air jointers)FESTO, Germany
    Main BearingNTN & NSK, Japan
    Time beltsGates, USA
    Convey beltsEuropean Brand

    Haina has many renowned suppliers from oversea and domestic market. We have established long-term partnership with them, also get customers' great satisfaction.



    Accessory equipment (Need to purchase separately):


    1. Stain camera system

    2. Air compressor

    3. Dust collector device

    4. Metal detecting instrument

    5. Ink-jet printer

    6. Perfume spray device



    Common question:


    Q1: How can we get the quotation?

    A1: Normally, we will provide offer within 24h, plz contact with us if hurry (Tel & Whatsapp: 008615059553620, Email: becky@fjhaina.com).

    Q2: What is the payment term?

    A2: 30% deposit before production, 60% before shipment, 10% after installation at buyer's side.

    Q3: Where is your factory, how can I visit you?

    A3: Haina machinery is located in Jinjiang City, Fujian province, China. You can take the flight to Quanzhou airport, we will go to pick you to our factory.

    Q4: What's your after-sale service?

    A4: When the machine was shipped from our factory, we will apply visa for engineer at once. When the machine arrives at your factory, we will dispatch them at once.

    Q5: Can you provide raw materials?

    A5: Sure, we cooperate with many raw material suppliers, they are all reliable suppliers and able to provide very good quality materials.
