    Full Servo 800Pcs/Min Elastic Waist Band Diaper Production Machine

    Ask Lasest Price
    Brand Name : HAINA
    Model Number : HNJX-UNK800
    Certification : CE
    Price : Negotiable
    Payment Terms : T/T, L/C
    Supply Ability : 72 SETS/YEAR
    Delivery Time : 150 Days
    • Product Details
    • Company Profile

    Full Servo 800Pcs/Min Elastic Waist Band Diaper Production Machine

    Elastic Waist Band CE Certified Baby Diaper Machinery With Full Servo Control


    Full Servo Baby Diapers Machine Parameters


    • Program System

    Servo driven, intelligent HMI touch screen man-machine interface

    • Tension System

    Tension control with buffer system, automatic web guiding system, to ensure materials stable working at zero speed splice.

    • Driven System

    Servo drive, digital size change, ensure run synchronously at full process.

    • Safety System

    Safety guard for operating side, emergency stop switch, security identifier, safety pull wire at driven side.

    • Auto Pack System

    Auto stacker and Packaging machine to be defined by customer need.

    • Web Guiding System

    BST ,Germany / FIFE, USA

    • Customized Function Available

    Diaper Structure Picture For Your Reference:


    1. Topsheet

    2. Hook / Velcro

    3. Leakcuff

    4. Elastic Waist

    5. Backsheet

    6. Frontal tape


    It is cutomized according to your required product.



    MachineElastic Waist Band CE Certified Baby Diaper Machinery With Full Servo Control
    ModelHNJX-UNK850
    ProductsBaby Diaper
    Products StructureUpper & Lower tissue paper, Cotton core ( mix with SAP), ADL, PE film, frontal tape, topsheet hydrophilic nonwoven, leg cuff hydrophobic nonwoven, S cut side tape, waistband online.

    Product Size

    NB, S, M, L, XL, XXL
    Glue MachineNordson / Chinese Brands Optional
    Design speed800 pcs/min
    Production speed700 pcs/min
    Defective rate≤3%
    Efficiency≥85%
    Power Supply3 Phase 380VAC, 50HZ (base on customer local power)
    Total Weight100 T customized
    Power

    ~300KW

    Required Air Compressor2m³/min, 0.6-0.8Mpa
    DimensionL~45m,W~8.0,H~6m
    Machine directionFrom right to left or left to right (According to the customer requirements)
    ColorCustomized


    Quick Details


    1. Applicable Industries:

    Hygiene industry

    2. Condition:

    New

    3. Product Type:

    Diaper Machine

    4. Place of Origin:

    China

    5. Brand Name:

    Haina

    6. After-sales Service Provided

    Engineers available to service machinery overseas, Free spare parts, Video technical support, Field installation, commissioning and training, Field maintenance and repair service, Online support.


    Accessory equipment (Need to purchase separately, you can ask Haina to purchase them for you or you purchase them by yourself)


    1. Stain camera system

    2. Air compressor

    3. Dust collector device

    4. Metal detecting instrument

    5. Ink-jet printer

    6. Perfume spray device



    Introduction


    Jinjiang Haina Machinery Co., Ltd is a very professional equipment manufacturer in China. Specializing in baby-diapers, adult-diapers, sanitary napkins machinery. With the spirit of keeping innovating and improving, Haina has made more achievements and earned very good reputation in this field during these years. Haina was listed on Hongkong exchange stock market successfully on June this year.(Stock code HK1645).



    Machine packing:


    The machine will be packed by international standard, anti-rusty treated and wrapped film packing or special part in wood carton package.
