| Brand Name : | HAINA |
| Model Number : | HNJX-UNK600 |
| Certification : | CE |
| Price : | Negotiable |
| Payment Terms : | T/T |
| Supply Ability : | 72 SETS/YEAR |
| Delivery Time : | 150 Days |
Customized Full Automatic Siemens System / PLC Baby Diaper Machinery
| Machine | Full Servo Remote Maintenance Baby Diaper Machinery |
| Model | HNJX-UNK600 |
| Products | Baby Diaper |
| Products Structure | Upper & Lower tissue paper, Cotton core ( mix with SAP), ADL, PE film, frontal tape, topsheet hydrophilic nonwoven, leg cuff hydrophobic nonwoven, S cut side tape, waistband online. |
| Product Size | NB, S, M, L, XL, XXL |
| Glue Machine | Nordson / Chinese Brands Optional |
| Design speed | 600 pcs/min |
| Production speed | 500 pcs / min |
| Defective rate | ≤3% |
| Efficiency | ≥85% |
| Power Supply | 3 Phase 380VAC, 50HZ (base on customer local power) |
| Total Weight | 100 T customized |
| Power | ~300KW |
| Required Air Compressor | 2m³/min, 0.6-0.8Mpa |
| Dimension | L~42m,W~8.0,H~4m |
| Machine direction | From right to left or left to right (According to the customer requirements) |
| Color | Customized |
Diaper Structure:
1. Topsheet
2. Hook
3. Leakcuff
4. Elastic Waist
5. Backsheet
6. Frontal tap
Servo driven, intelligent HMI touch screen man-machine interface
Tension control with buffer system, automatic web guiding system, to ensure materials stable working at zero speed splice.
Servo drive, digital size change, ensure run synchronously at full process.
Servo drive, digital size change, ensure run synchronously at full process.
Safety guard for operating side, emergency stop switch, security identifier, safety pull wire at driven side.
Auto stacker and Packaging machine to be defined by customer need.
BST , Germany / FIFE, USA
Accessory equipment
(Need to purchase separately, you can ask Haina to purchase them for you or you purchase them by yourself)
1. Stain camera system
2. Air compressor
3. Dust collector device
4. Metal detecting instrument
5. Ink-jet printer
6. Perfume spray device
