400KW 300PPM O Shape Lady Menstrual Pad Making Machine

    Buy cheap 400KW 300PPM O Shape Lady Menstrual Pad Making Machine from wholesalers

    Buy cheap 400KW 300PPM O Shape Lady Menstrual Pad Making Machine from wholesalers
    • Buy cheap 400KW 300PPM O Shape Lady Menstrual Pad Making Machine from wholesalers
    • Buy cheap 400KW 300PPM O Shape Lady Menstrual Pad Making Machine from wholesalers
    • Buy cheap 400KW 300PPM O Shape Lady Menstrual Pad Making Machine from wholesalers
    • Buy cheap 400KW 300PPM O Shape Lady Menstrual Pad Making Machine from wholesalers

    400KW 300PPM O Shape Lady Menstrual Pad Making Machine

    Ask Lasest Price
    Brand Name : HAINA
    Model Number : HNJX-CLK350
    Certification : ISO,CE,
    Price : negoiatbale
    Payment Terms : T/T
    Supply Ability : 6 Sets per Month
    Delivery Time : 180 working days
    • Product Details
    • Company Profile

    400KW 300PPM O Shape Lady Menstrual Pad Making Machine

    Easy Maintenance O Shape Lady Menstrual Pad Making Machine price


    Main technical parameters:


    MachineEasy Maintenance O Shape Lady Menstrual Pad Making Machine price
    ModelHNJX-CLK350
    Products

    Lady Menstrual Pants Diaper

    Design speed350 pcs/min
    Production speed250-300 pcs/min(M Size)
    Defective rate≤3%
    Efficiency≥85%
    Power Supply3 Phase 380VAC, 50HZ (base on customer local power)
    Total WeightAround 95T
    Power~400KW
    Required Air Compressor2m³/min,0.6-0.8Mpa
    DimensionL~45m,W~10m,H~4m
    Machine directionFrom right to left (According to the customer requirements)

    Color

    Car white (As required)

    See Machine Running Video on Youtube
    https://youtu.be/8ALyiiWH2XM
    Our Main Supplier

    Configuration and options:

    ►Drive System: The whole machine adopt servo motor driven, size change by interface.

    ►Inspection system: Auto raw material joint rejecting and alarm;

    ►Unwind and splice: Use Dual pneumatic shaft, independent servo unwinds auto joint material. Splice speed can be setup by interface.

    ►Human-machine interface:

    1. Interface install at machine middle position, English and Chinese language, and LED screen display.
    2. Raw material lacking, jointer, splice, fans, vacuum pump jump-off, all display on the screen.
    3. Rejection position and quantity can be set up.

    4) Production speed (pcs/min), shift output, rejecting quantity, total capacity, is interface display.

    ►Safety devices:

    With safety frame and door.

    Frontal and ear side E-stop and safety line.

    Speed up and down, alarm device button, easy operation.

    Back drive upper layer add loft.

    ►Glue spray and coating control

    1. Reserved hot melt application position, spray and coating head keeps 90 degree towards materials, hoses fix-up at rear side, perforated vertical through face board.
    2. Working with hot melt units, can automatic spray and stop, manual control enabled.
    3. Supply 0-10V CD glue auto tracking signal. Angle control inside, controlled by separate servo motor
    4. Lamp installed at hot melt positions.


    Please feel free to contact us for more info !
